High-power 8-inch platform for QFN, BGA and PCB packaging
The QSD0830 is a high-power 8-inch precision dicing saw purpose-engineered for the demanding requirements of semiconductor packaging — QFN, BGA, PCB and large-format leadframe singulation. With a high-torque DC spindle and large-travel XY stage, it handles tough composite substrates that smaller dicing saws cannot process efficiently.
High-torque drive for cutting tough composite materials — copper-rich leadframes, multilayer PCBs, BGA substrates.
High-accuracy linear positioning with closed-loop encoder feedback for repeatable results.
Optical alignment system for automated street recognition and offset compensation.
Configurable for silicon, GaAs, sapphire, ceramics, glass, LiNbO₃ and more.
Accepts Qisheng full blade range plus industry-standard hub blade specifications.
Free software upgrades for the lifetime of the machine — no hidden subscription fees.
All specifications are typical values. Custom configurations available on request — please contact our European technical sales team for project-specific requirements.
| Maximum wafer size | 8" (200 mm) |
|---|---|
| Spindle type | High-power DC |
| Spindle speed | Configurable (specifications on request) |
| Cutting accuracy | ±3 μm typical |
| XY stage type | Linear servo with optical encoder |
| Pattern recognition | Automatic optical alignment system |
| Power supply | 380 V AC, 3-phase |
| Compressed air | 0.5–0.7 MPa, dry & clean |
| Cooling water | DI water, filtered, recirculated |
| Compatible blades | Qisheng full range + third-party hub blades |
| Warranty | 12 months standard, lifetime software updates |
Specifications subject to change without notice. Please confirm latest values with sales when placing order.
The QSD0830 is deployed across multiple industries and substrate types:
The QSD0830 accepts the full range of Qisheng Precision dicing blades — resin-bond, metal-bond and electroformed — as well as third-party hub blades from major suppliers. Compatible accessories include ceramic vacuum chuck tables, diamond dresser boards and custom flanges manufactured in-house.
Get a personalised quotation, discuss your specific application requirements, or request a live demonstration. Our European technical sales team responds to all enquiries within one business day.
